Groove|Tenon: Adjustable D.160 Shaper Grooving Cutters

Rangate Adjustable ø160mm Grooving Shaper Cutters
R2AG1600595 R2AG1600815 R2AG1601530

Our adjustable groovers allow you to cut precise grooves which require no sanding or touch-ups, adjustable to a good range of applications. Each comes with spacers to enable one set to perform a range grooving operations. Higher range tools can be used together as a part of mortise and tenon joinery millwork.

• R2AG1600595: Adjustable Grooving from 5 to 9.5mm.
• R2AG1600815: Adjustable Grooving from 8 to 15mm.
• R2AG1601530: Adjustable Grooving from 15.6 to 30mm.

RPM: 4700 to 9800 depending on the specific tool range.

Bore size: 1-1/4".

Each tool comes with the spacers and shims necessary to achieve the full range of groove widths within the min/max specs of the tool.

This cutter comes fully equipped with nano diamond-treated solid carbide insert knives, along with the correct T-wrench(es) for replacements.

Tool Drawings:

• 5 to 9.5mm
• 8 to 15mm and 15.6 to 30mm
